2.5SDM Submersible Deep Well Pump For Clean Water And Irrigation
| Quantity: | |
|---|---|
Application & Fluid Transfer Capabilities
Engineered for demanding agricultural and municipal environments, this submersible deep well pump is specifically calibrated for pumping clean water with sand content less than 150g/m3. When handling groundwater extraction, the precision-machined impellers maintain a consistent volumetric flow without premature wear, even when trace particulates are present in the aquifer. The tactile, cool stainless steel exterior reflects its industrial-grade construction, designed to resist the corrosive elements naturally found in deep underground reservoirs.
This unit provides exceptional high-head and large-flow output, making it highly versatile across multiple large-scale scenarios. It is explicitly designed For well pumping, river pumping, farm irrigation, water supply. Whether deployed in expansive agricultural irrigation networks requiring sustained pressure, or municipal water supply systems demanding uninterrupted daily operation, the pump delivers a steady, low-vibration hum that signifies reliable mechanical performance.
Operating Conditions & Environmental Tolerance
To ensure optimal mechanical integrity and prevent thermal overload during continuous extraction cycles, this pump is built to operate within strict environmental parameters. The heavy-duty casing and internal cooling mechanisms allow it to function flawlessly with a Water temperature up to 35℃, ensuring the internal motor components remain within safe thermal limits even during prolonged summer irrigation schedules. Furthermore, the system is rated for an Ambient temperature permissible up to 40℃, accommodating installations in hot, arid climates without compromising electrical efficiency.
Dimensional & Depth Specifications
Physical installation constraints are a critical factor in deep well deployment. This unit features a slim, space-efficient profile specifically engineered for narrow boreholes. The 2.5SDM Minimum internal diameter of well: 2.5"(65mm) requirement ensures smooth insertion and retrieval without damaging the well casing. Built to withstand immense hydrostatic pressure, the pump boasts a Maximum immersion depth:80m, allowing access to deep, unpolluted aquifers while maintaining a tight, leak-proof seal across all mechanical joints.
Motor Specifications & Core Craftsmanship
At the heart of this fluid transfer system lies a meticulously wound, pure copper motor coil, housed within a high-strength stainless steel body. This combination not only provides a dense, solid weight indicative of its durability but also guarantees long-lasting wear resistance and anti-corrosion performance in complex underground environments. The copper windings maximize electrical conductivity, translating into exceptional energy efficiency and reduced operational costs over the equipment's lifespan.
| Motor Type | Rewindable motor |
| Thermal Rating | Insulation Class B |
| Ingress Defense | Protection IP68 |
| Mounting Protocol | NEMA dimension standards |
The Rewindable motor design offers significant maintenance advantages, allowing for localized repairs rather than complete unit replacement, thereby lowering long-term ownership costs. With an Insulation Class B rating, the motor safely dissipates internal heat, while the rigorous Protection IP68 standard ensures absolute dust and water ingress prevention under extreme submerged pressure. Adherence to NEMA dimension standards guarantees universal compatibility with standard coupling interfaces, streamlining the installation process for engineering teams.
Options on Request & Customization Capabilities
Recognizing that different infrastructure projects require specific electrical and mechanical configurations, we provide comprehensive OEM/ODM customization services. This includes global multi-voltage and frequency adaptations to ensure seamless integration into localized power grids. Our flexible manufacturing process allows procurement managers to specify exact requirements, tailoring the pump to match precise architectural and engineering blueprints.
Available Configurations
- Sealing Upgrades: A Special mechanical seal can be integrated for environments with challenging chemical profiles or abrasive micro-particles, extending the maintenance interval.
- Electrical Variations: Choose a Single phase motor with built-in capacitor for compact, straightforward installations, or a Single phase motor with control box for enhanced external monitoring and surge protection.
- Connection Specifications: The length of cable:2 Meter comes as a standard baseline, with flexible extension options available to match your specific well depth requirements.
- Plumbing Interface: Standard Outlet dimension :1" ensures immediate compatibility with common industrial and agricultural piping networks.
Manufacturing Standards & Global Delivery Assurance
Beyond the physical hardware, the value of this pumping solution is anchored in rigorous international quality control. Every unit passes through stringent performance and safety testing protocols before leaving the facility, proudly carrying CE and ISO9001 certifications. This commitment to documented quality ensures that large-scale installations proceed without the risk of out-of-box failures.
To protect your investment during cross-border transit, we utilize industrial-grade packaging solutions. Pumps are secured in reinforced wooden crates or standardized, shrink-wrapped pallets, absorbing transit shocks and preventing moisture ingress during ocean freight. Furthermore, we back our engineering with a comprehensive one-year warranty and dedicated technical support, significantly mitigating operational risks and providing absolute peace of mind for volume procurement professionals.
