ML Single Phase Two-Value Capacitor Asynchronous Motor
| Quantity: | |
|---|---|
Product introduction:
Aluminum housing, aluminum front and back cover, aluminum terminal box, aluminum feet which is removable. The installation position can be changed.Terminal box comes with power wire protection screw sleeve. Light-weight, high thermal conductivity, low noise, energy saving and beautiful appearance. Long service life, good sealing, oxidation resistance, corrosion resistance, which result in usage in humid environment no matter indoor or outdoor.Over current protector and overheat protector are optional, which can prolong the working life and increase safety of motor. The motor is widely used as the power source for fan, water pump, air compressor, injection molding machines and other equipments.
Operating conditions:
Ambient air temperature:-15℃≤0≤40℃
Altitude:≤1000m
Rated frequency:50Hz/60Hz
Wiring method: the rotation direction of motor can be changed by the wiring method
Working type:S1 (continuous working system)
Insulation class: B
Protection grade:IP54 or IP55
Cooling type:IC411
Use
Three-phase asynchronous motors have high power and are mainly made into large motors. It is generally used in large industrial equipment with triple-phase power. The first thing to note is that three-phase asynchronous motors are only used for electric motors and rarely used as generators. They are all synchronous motors for generating electricity.
For low-power three-phase asynchronous motors below 1kW, not only can it be used for three-phase operation, but it can also be used for single-phase operation.
Product introduction:
Aluminum housing, aluminum front and back cover, aluminum terminal box, aluminum feet which is removable. The installation position can be changed.Terminal box comes with power wire protection screw sleeve. Light-weight, high thermal conductivity, low noise, energy saving and beautiful appearance. Long service life, good sealing, oxidation resistance, corrosion resistance, which result in usage in humid environment no matter indoor or outdoor.Over current protector and overheat protector are optional, which can prolong the working life and increase safety of motor. The motor is widely used as the power source for fan, water pump, air compressor, injection molding machines and other equipments.
Operating conditions:
Ambient air temperature:-15℃≤0≤40℃
Altitude:≤1000m
Rated frequency:50Hz/60Hz
Wiring method: the rotation direction of motor can be changed by the wiring method
Working type:S1 (continuous working system)
Insulation class: B
Protection grade:IP54 or IP55
Cooling type:IC411
Use
Three-phase asynchronous motors have high power and are mainly made into large motors. It is generally used in large industrial equipment with triple-phase power. The first thing to note is that three-phase asynchronous motors are only used for electric motors and rarely used as generators. They are all synchronous motors for generating electricity.
For low-power three-phase asynchronous motors below 1kW, not only can it be used for three-phase operation, but it can also be used for single-phase operation.
