Application
Suitable for use with clean water that does not contain abrasive particles and liquids that are not chemically aggressive towards the materials from which the pump is made.
They are easy to use and are economical, they are ideal for domestic use and in particular for distributing water in combination with small pressure sets and for the irrigation of gardens and allotments. The pump comes complete with a flap-check valve.
Keep the water pressure stable to let water heater normally working.
The pump should be installed in an enclosed environment, or at least sheltered from iclement weather.
Motor
※ Two-pole induction motor(n=2850 r.p.m)
※ Insulation Class B
※ Protection IP44
※ Continuous service S1
※ Thermal protector
Operating conditions
※ Liquid temperature up to 60°C
※ Ambient temperature up to 40°C
※ Total suction lift up to 8m
Component Construction
※ Pump body: POM + Brass
※ Pump cover: Pure Brass
※ Motor housing: Aluminum
※ Impeller: Brass
※ Motor shaft: AISI304 SS
※ Mechanical seal: Ceramic/Graphite
Use Advantage
Cost saving: The fully automatic variable frequency booster pump does not require the construction of pools and water tanks, and occupies a relatively small space, thus saving the initial sponsorship of the equipment and saving the consumption of the flushing pool.
Safety and sanitation: the water pump is directly connected to the tap water pipe network, the surge tank is used as a water pump storage device, the vacuum eliminator is used to eliminate the negative pressure generated in the pipe network, and the faucet water pipe network is directly connected with the pressure regulator. The water tank is used as an inlet and storage device for the water pump. Therefore, the water pump is a fully enclosed structure, which truly eliminates the secondary pollution of the water supply and ensures the safety and sanitation of the pressurized water quality.
Fully automatic operation: The automatic tap water pressurization system of the water pump is fully automatic and intelligently controlled, with dry running and thermal overload protection functions. After plugging in the power supply, it can realize automatic pressure, without manual duty, easy to use.
