Swimming pool pumps(HFC)

Application

Filter centrifugal pumps are designed for cleaning swimming pool, They are suitable to transfer high volumes of water(not exceeding 45°C) against low head.

The pump should be installed in an enclosed environment, or at least sheltered from iclement weather.

Motor

※ Two-pole induction motor(n=2850 r.p.m)

※ Insulation Class B

※ Protection IP44

※ Continuous service S1

※ Thermal protector for single phase

Operating conditions

※ Liquid temperature up to 45°C

※ Ambient temperature up to 40°C

※ Total suction lift up to 8m

Component             Construction

※ Pump body:                  Techno-polymer

※ Pump support:              Aluminum

※ Motor housing:              Alloy

※ Impeller:                      Techno-polymer

※ Motor shaft:                 AISI304 SS

※ Mechanical seal:           Ceramic/Graphite

Product Information

This pool pump blends cost-efficient design with durable construction,it features a totally balanced, efficient Noryl impeller to produce higher flow rates at less horsepower than other pumps, so users can run pump less and save on electricity.
