Swimming pool pumps(HFC-01)
| Quantity: | |
|---|---|
Application
Filter centrifugal pumps are designed for cleaning swimming pool,they are suitable to transfer high volumes of water against low head(not exceeding 45C).The range of Happy pool pumps are economical pumps that are ideal for small, medium or large sized residential swimming pools, available in thirteen models sized from 0.33 horsepower to 3 horespower.We are striving to provide with maximum performance at an affordable price.
The pump should be installed in an enclosed environment, or at least sheltered from inclement weather.
Motor
※ Two-pole induction motor(n=2850 r.p.m)
※ Insulation Class B
※ Protection IP44
※ Continuous service S1
※ Thermal protector for single phase
Operating conditions
※ Liquid temperature up to 45°C
※ Ambient temperature up to 40°C
※ Total suction lift up to 8m
Component Construction
※ Pump body: Techno-polymer
※ Pump support: Aluminum
※ Motor housing: Aluminum
※ Impeller: Techno-polymer
※ Motor shaft: AISI304 SS
※ Mechanical seal: Ceramic/Graphite
It has super powerful pumps for pools of all types and sizes, underground spas. The large filter housing allows for high water flow. A filter basket with internal ribs ensures flow when filling leaves and debris. The one-piece housing without bolts ensures ultra-quiet operation. High-tech motors are made of qualified materials for lower operating temperatures and longer service life.
Application
Filter centrifugal pumps are designed for cleaning swimming pool,they are suitable to transfer high volumes of water against low head(not exceeding 45C).The range of Happy pool pumps are economical pumps that are ideal for small, medium or large sized residential swimming pools, available in thirteen models sized from 0.33 horsepower to 3 horespower.We are striving to provide with maximum performance at an affordable price.
The pump should be installed in an enclosed environment, or at least sheltered from inclement weather.
Motor
※ Two-pole induction motor(n=2850 r.p.m)
※ Insulation Class B
※ Protection IP44
※ Continuous service S1
※ Thermal protector for single phase
Operating conditions
※ Liquid temperature up to 45°C
※ Ambient temperature up to 40°C
※ Total suction lift up to 8m
Component Construction
※ Pump body: Techno-polymer
※ Pump support: Aluminum
※ Motor housing: Aluminum
※ Impeller: Techno-polymer
※ Motor shaft: AISI304 SS
※ Mechanical seal: Ceramic/Graphite
It has super powerful pumps for pools of all types and sizes, underground spas. The large filter housing allows for high water flow. A filter basket with internal ribs ensures flow when filling leaves and debris. The one-piece housing without bolts ensures ultra-quiet operation. High-tech motors are made of qualified materials for lower operating temperatures and longer service life.
