Submersible Deep Well Pump(2.5SDM)
| Quantity: | |
|---|---|
Application
For pumping clean water with sand content less than 150g/m3
For well pumping, river pumping, farm irrigation, water supply.
Operating conditions
Water temperature up to 35℃
Ambient temperature permissible up to 40℃
2.5SDM Minimum internal diameter of well: 2.5"(65mm)
Maximum immersion depth:80m
Motor
Rewindable motor
Insulation Class B
Protection IP68
NEMA dimension standards
Options on request
Special mechanical seal
Single phase motor with built-in capacitor
Single phase motor with control box
The length of cable:2 Meter
Outlet dimension :1"
Application
For pumping clean water with sand content less than 150g/m3
For well pumping, river pumping, farm irrigation, water supply.
Operating conditions
Water temperature up to 35℃
Ambient temperature permissible up to 40℃
2.5SDM Minimum internal diameter of well: 2.5"(65mm)
Maximum immersion depth:80m
Motor
Rewindable motor
Insulation Class B
Protection IP68
NEMA dimension standards
Options on request
Special mechanical seal
Single phase motor with built-in capacitor
Single phase motor with control box
The length of cable:2 Meter
Outlet dimension :1"
