Submersible Deep Well Pump(3.5SDM)
| Quantity: | |
|---|---|
Application
For pumping clean water with sand content less than 150g/m3
For well pumping, river pumping, farm irrigation, water supply.
Operating conditions
Water temperature up to 35℃
Ambient temperature permissible up to 40℃
3.5SDM Minimum internal diameter of well: 3.5"(90mm)
Maximum immersion depth:80m
Motor
Rewindable motor
Insulation Class B
Protection IP68
NEMA dimension standards
Options on request
Special mechanical seal
Single phase motor with built-in capacitor
Single phase motor with control box
The length of cable: 2m
Outlet dimension : 1/"，1½"
